Raphael 01M 707 Table Full

Specifications

• Table length – 6′ (fully retracted) / 7’8″ (fully extended)
• Cushion width –  22″
• Width of arm rests (widest part of table) – 27″
• Weight 600 lbs   66 cubic feet
• dimensions: 35″ W x 83″ L x 39″ H
• Cervical Motions:
  • 20° flexion       15° extension
  • 20° lateral flexion – right or left
  • 20° rotation – each way off center
  • circumduction (combined lateral flexion and flexion)
• Table Height Elevation –  24″ minimum / 35 3/4″ maximum
• Caudal Motions:
  • 16° flexion       8° extension
  • 5° lateral flexion – right or left
  • circumduction (combined lateral flexion and flexion)
• 400 pound weight limit on up/down column mechanism
• 400 pound weight limit on range of motion mechanisms in fully retracted position
