Electric Wheelchair FC-P5 (24V/10Ah Lithium Battery)

Electric Wheelchair FC-P5 (24V/10Ah Lithium Battery)

Lightweight Folding Electric Wheelchair for Disabled Adults FC-P5

1. Advantages:

1.Lightweight: With a weight of 26kg, the complete wheelchair is both firm and lightweight

2.Firm: Strong compressive strength, hard to deform, long service life

3.Durable: Environmentally-friendly color, powder coating, corrosion-resistant, wear-resistant

2.Features:

1.The frame is made of 6061 aeronautical aluminum-Magnesium alloy material, with surface baking-painted, beautiful, lightweight, and corrosion-resistant.

2.Soft back cushion.

3.The armrests can be upturned to help the user to get on and off

4.Imported Chip controller.

5.Foldable connecting rod: Connecting rods of front and rear wheels reflect different folding concept; the folding mode is the most ideal and small-sized type.

6. 8-inch high-quality large tires.

7.Comfortable foot pedal.

8.Imported chip motor: Double motors achieve the power up to 500w, so the wheelchair can climb slopes easily

9.With a standard configuration of a 24V/10Ah lithium battery.

Can reach a cruising distance of 20 km

10.The wheelchair body can be quickly folded , 0.13㎡ volume makes travel easier



Specifications:

TIM截图20180611184610

  • Description
  • Reviews (0)

Product Description

Portable Hospital Folding Lightweight Transport Wheelchair

Portable Hospital Folding Lightweight Transport Wheelchair



FC-P1 Foldable Lightweight Electric wheelchair↓



electric wheelchair controller Chip controller wheelchair motorPowerful chip motor; double motors achieve

the power up to 500w, so the wheelchair

can climb slopes easily

wheelchair batteries

With a standard configuration of a lithium battery.

Can reach a cruising distance of 20 km.



wheelchair armrestsThe armrests can be upturned to help

the user to get on and off

foldable electric wheelchair

The wheelchair body can be quickly folded, 0.13 mᵌ volume makes travel easier

Total length (mm) 980
Total width (mm) 610
Total height (mm) 900
Seat depth (mm) 440
Seat width (mm) 440
Seat height (mm) 500
Speed per hour (km/h) ≤6
Maximum load (kg) 200
Maximum speed (km/h) 7.2
Mileage (km) 17
Damping system 2
Motor power (V/W) 24/250×2
Charger (V/2A) 24
KM of endurance (KM) ≥20
Battery (V/Ah) 24/10
Charging time (h) 3-5
Front wheel (inch) 8″
Rear wheel (inch) 8″
Net weight (kg) 25.6
Wheel base (mm) 650
Maximum gradeability (   °) 12
